Evaluation Board User Guide
ORDERING INFORMATION
BILL OF MATERIALS
Table 1.
UG-040
Qty
18
Designator
C85, C90 to C94, C101 to C103,
C107, C108, C110, C115, C116,
Description
Multilayer ceramic capacitor,16 V, X7R
(0402)
Manufacturer
Panasonic EC
Part Number
ECJ-0EX1C104K
C121, C127, C132, C134
50
C1, C2, C5, C7 to C10, C20, C21,
C28, C29, C38, C42, C48 to C51,
C58 to C60, C62, C64, C69, C73,
Multilayer ceramic capacitor, 50 V, X7R
(0603)
Panasonic EC
ECJ-1VB1H104K
C76, C79, C82, C97, C99, C112,
C118, C122, C128, C135, C146,
C147, C149, C151, C155, C156,
C158, C162, C168, C174, C176,
C177, C193, C194, C197, C203
9
C37, C65, C67, C83, C88, C124,
Multilayer ceramic capacitor, 50 V, NP0
Panasonic EC
ECJ-1VC1H102J
C129, C157, C160
(0603)
12
R28, R30, R51, R59, R166, R167,
R169, R172, R185, R189, R212,
Chip resistor, 100 kΩ, 1%, 125 mW, thick
film (0603)
Panasonic EC
ERJ-3EKF1003V
R214
8
C68, C71, C87, C89, C130, C138,
Multilayer ceramic capacitor, 50 V, NP0
Panasonic EC
ECJ-1VC1H101J
C159, C161
(0603)
16
R24, R31, R44, R60, R77, R84, R93,
R106, R136, R149, R159, R170,
Chip resistor, 100 kΩ, 1%, 100 mW, thick
film (0603)
Panasonic EC
ERJ-3EKF1000V
R180, R191, R207, R217
1
C84
Aluminum electrolytic capacitor, 100 μF,
Panasonic EC
EEE-FC1C101P
16 V, FC 105 deg, SMD_E
32
R6, R7, R13, R14, R18, R20, R40,
Chip resistor, 10 kΩ, 1%, 125 mW, thick film
Panasonic EC
ERJ-3EKF1002V
R43, R47 to R49, R54, R55, R63,
R64, R74, R78, R80, R82, R158,
R164, R186, R224 to R227, R232 to
R237
(0603)
3
C6, C39, C40
Multilayer ceramic capacitor, 25 V, NP0
TDK Corp
C1608C0G1E103J
(0603)
12
C15 to C17, C81, C86, C95, C98,
Multilayer ceramic capacitor, 100 V, NP0
Panasonic EC
ECJ-1VC2A100D
C170, C175, C178, C180, C183
(0603)
12
C104, C106, C109, C111, C117,
Multilayer ceramic capacitor, 50 V, NP0
Kemet
C0402C100J5GACTU
C123, C140 to C145
(0402)
5
C3, C4, C74, C96, C126
Aluminum electrolytic capacitor, 16 V, FC
Panasonic EC
EEE-FC1C100R
105 deg, SMD_B
4
C61, C77, C113, C150
Multilayer ceramic capacitor, 50 V NP0
Panasonic EC
ECJ-1VC1H121J
(0603)
1
R117
Chip resistor, 1 kΩ, 1% 125 mW thick film
Panasonic EC
ERJ-3EKF1001V
(0603)
3
9
D1, D3, D4
C23, C33, C43, C55, C114, C166,
TVS Zener, 15 V, 600 W, SMB
Multilayer ceramic capacitor, 50 V, NP0
ON Semiconductor
Murata Electronics
1SMB15AT3G
GRM1885C1H222JA01D
C184, C188, C200
(0603)
1
C36
Multilayer ceramic capacitor, 50 V, NP0
Murata ENA
GRM21B5C1H223JA01L
(0805)
2
C153, C154
Multilayer ceramic capacitor, 50 V, NP0
Panasonic EC
ECJ-1VC1H220J
(0603)
8
R76, R81, R90, R101, R134, R141,
Chip resistor, 237 Ω, 1%, 125 mW, thick film
Panasonic EC
ERJ-3EKF2370V
R157, R168
(0603)
2
R1, R4
Chip resistor, 243 Ω, 1%, 100 mW, thick film
Panasonic EC
ERJ-3EKF2430V
(0603)
10
R91, R94, R98, R99, R108, R109,
Chip resistor, 24.9 Ω, 1%, 63 mW, thick film
Rohm
MCR01MZPF24R9
R114, R115, R118, R123
(0402)
Rev. 0 | Page 27 of 32
